Real-Time Graphics Programming
Real-time graphics programming turns scene data into displayable images fast enough for interaction. It coordinates CPU work, GPU resources, shaders, visibility, rasterization, and presentation under a fixed time budget for each frame.
itSoftware engineering | OpenSkills.info
Recommended first:game-engine-fundamentals
Course pathWalk it in order
Look it upDip in anytime
Go furtherLeaves this page
Intro
Real-Time Graphics Programming
Real-time graphics programming produces a new image while an application is running, usually in response to input, animation, simulation, or camera movement. Unlike offline rendering, it must finish each frame before the next display deadline. A target of 60 frames per second allows about 16.67 milliseconds per frame; 120 frames per second allows about 8.33 milliseconds.
The application and graphics processor share the work. The CPU updates the world, determines visible objects, prepares resource bindings, and records rendering commands. A graphics API submits those commands to one or more GPU queues. The GPU consumes buffers and textures, runs shader programs across many data items, writes render targets, and presents the completed image through a swap chain.
From scene to screen
A frame begins with scene state: transforms, cameras, lights, geometry, materials, and animation results. The renderer derives a view of that state rather than drawing the scene graph directly. It culls work that cannot affect the camera, sorts the remaining work when ordering matters, and groups draws that share pipeline state.
Geometry reaches the GPU through vertex and index buffers. A vertex shader transforms each vertex from model space through world and view space into clip space. Clipping removes portions outside the viewing volume. Perspective division produces normalized device coordinates, and viewport mapping converts them to window coordinates.
